Specifications
Dimensions
Dimensions
4.55 inches (115.5 mm) long, 1.89 inches (48 mm) maximum diameter
Electrical
Phantom Power Requirements
11-52V DC, 3 mA typical
Audio
Polar Pattern
Cardioid
Frequency Response
20 Hz - 20 kHz
Output Impedance
100 ohms
Sensitivity
-43 dBV/Pa (7.0 mV)
Signal-to-Noise Ratio
83 dB, 1 kHz at 1 Pa
Connectivity
Maximum Input Sound Level
148 dB SPL, 1 kHz at 1% T.H.D., 158 dB SPL, with 10 dB pad (nominal)
Connector
3-Pin XLRM
Shipping
Weight
6 oz (170 g)
General
Transducer Type
Condenser
Low Frequency Roll Off
80 Hz, 12 dB/octave
Noise
11 dB SPL
Dynamic Range
137 dB, 1 kHz at Max SPL
Switches
High-pass filter, 10 dB pad (nominal)
