Specifications
Dimensions
Dimensions
7.05 inches (179 mm) long, 1.97 inches (50 mm) head diameter, 1.3-0.87 inches (33 - 22 mm) tapered body diameter
Electrical
Phantom Power Requirements
11-52V DC, 4 mA typical
Audio
Polar Pattern
Cardioid
Frequency Response
20 Hz - 20 kHz
Output Impedance
150 ohms
Sensitivity
-40 dBV/Pa (10.0 mV)
Signal-to-Noise Ratio
80 dB, 1 kHz at 1 Pa
Connectivity
Maximum Input Sound Level
147 dB SPL, 1 kHz at 1% T.H.D., 157 dB SPL, with 10 dB pad (nominal)
Connector
3-Pin XLRM
Shipping
Weight
11.6 oz (330 g)
General
Transducer Type
Condenser
Low Frequency Roll Off
80 Hz, 12 dB/octave
Noise
14 dB SPL
Dynamic Range
133 dB, 1 kHz at Max SPL
Switches
High-pass filter, 10 dB pad (nominal)
