Specifications
Dimensions
Dimensions
6.69 inches (170 mm) long, 2.05 inches (52 mm) maximum body diameter
Weight
Weight 14.2 Oz
(403 g)
Electrical
Phantom Power Requirements
11-52V DC, 3.8 mA typical
Audio
Polar Pattern
Cardioid
Frequency Response
20 Hz - 20 kHz
Output Impedance
120 ohms
Sensitivity
-33 dBV/Pa (22.4 mV)
Signal-to-Noise Ratio
82 dB, 1 kHz at 1 Pa
Connectivity
Maximum Input Sound Level
148 dB SPL, 1 kHz at 1% T.H.D., 158 dB SPL, with 10 dB pad (nominal)
Connector
3-Pin XLRM
General
Transducer Type
Condenser
Low Frequency Roll Off
80 Hz, 12 dB/octave
Noise
12 dB SPL
Dynamic Range
136 dB, 1 kHz at Max SPL
Switches
Flat, roll-off, 10 dB pad (nominal)
