Specifications
Dimensions
Max. Body Diameter
2.10"
Electrical
Phantom Power Requirements
48V DC, 3.4 mA typical
Audio
Polar Patterns (selectable)
Cardioid, Figure-8, Omnidirectional
Frequency Response
20 Hz - 18 kHz
Output Impedance
100 ohms
Sensitivity
-42 dBV/Pa (7.9 mV)
Signal-to-Noise Ratio
80 dB, 1 kHz at 1 Pa
Connectivity
Maximum Input Sound Level
155 dB SPL, 1 kHz at 1% T.H.D., 165 dB SPL, with 10 dB pad (nominal)
Connector
3-Pin XLRM
Shipping
Weight
524 g (18.5 oz)
Identifiers
Length
7.40"
General
Transducer Type
Condenser
Low Frequency Roll Off
80 Hz, 12 dB/octave
Noise
14 dB
Dynamic Range
141 dB, 1 kHz at Max SPL
Switches
Polar selection, Flat, roll-off, 10 dB pad (nominal)
