Specifications
Dimensions
Dimensions
6.10") long, 0.83" maximum body diameter
Electrical
Phantom Power Requirements
48V DC, 4.8 mA typical
Audio
Polar Pattern
Omnidirectional
Frequency Response
20 Hz - 20 kHz
Output Impedance
50 ohms
Sensitivity
-34 dBV/Pa (19.9 mV)
Signal-to-Noise Ratio
78 dB, 1 kHz at 1 Pa
Connectivity
Maximum Input Sound Level
145 dB SPL, 1 kHz at 1% T.H.D., 155 dB SPL, with 10 dB pad (nominal)
Connector
3-Pin XLRM
Shipping
Weight
130 g (4.6 oz)
General
Transducer Type
DC Bias Condenser
Low Frequency Roll Off
80 Hz, 18 dB/octave
Noise
16 dB SPL
Dynamic Range
129 dB, 1 kHz at Max SPL
Switches
Flat, roll-off; 10 dB pad (nominal)
