Specifications
Dimensions
Dimensions
7.40" long, 2.10" maximum body diameter
Electrical
Phantom Power Requirements
48V DC, 4.2 mA typical
Audio
Polar Patterns (selectable)
Cardioid, Figure-8, Omnidirectional
Frequency Response
20 Hz - 18 kHz
Output Impedance
100 ohms
Sensitivity
-36 dBV/Pa (15.8 mV)
Signal-to-Noise Ratio
77 dB, 1 kHz at 1 Pa
Connectivity
Maximum Input Sound Level
149 dB SPL, 1 kHz at 1% T.H.D., 159 dB SPL, with 10 dB pad (nominal)
Connector
3-Pin XLRM
Shipping
Weight
18.0 oz (510 g)
General
Transducer Type
DC Bias Condenser
Low Frequency Roll Off
80 Hz, 12 dB/octave
Noise
17 dB
Dynamic Range
132 dB, 1 kHz at Max SPL
Switches
Polar selection, Flat, roll-off, 10 dB pad (nominal)
