Specifications
Dimensions
Dimensions
193.0 mm (7.60") long, 53.4 mm (2.10") maximum body diameter
Electrical
Phantom Power Requirements
48V DC, 6.4 mA typical (both channels total)
Audio
Polar Patterns (selectable)
Cardioid, Figure-8
Frequency Response
20 Hz - 18 kHz
Output Impedance
50 ohms
Connectivity
Maximum Input Sound Level
159 dB SPL, with 10 dB pad (nominal)
Connector
5-Pin XLRM
Construction
Cable
5.0 m (16.5') long, 8-conductor, shielded, vinyl-jacketed stereo cable with 5-pin XLRF-type connector at microphone end and two 3-pin XLRM-type connectors at output end
Shipping
Weight
517 g (18.2 oz)
General
Transducer Type
DC Bias Condenser
Stereo 90°
-42 dBV/Pa (7.9 mV)
Stereo 127°
-41 dBV/Pa (8.9 mV)
Mid
-36 dBV/Pa (15.8 mV)
Side
-36 dBV/Pa (15.8 mV)
Low Frequency Roll Off
80 Hz, 12 dB/octave
Mid and Side
149 dB SPL, 1 kHz at 1% T.H.D.
Switches
90°, 127°, M-S, Flat, roll-off, 10 dB pad (nominal)
