Specifications
Dimensions
Dimensions
6.1 inches (155.0 mm) long, 0.83 inch (21 mm) maximum body diameter
Electrical
Phantom Power Requirements
48V DC, 3.0 mA typical
Audio
Polar Pattern
Figure-8
Frequency Response
30 Hz - 18 kHz
Output Impedance
100Ω
Open Circuit Sensitivity
-42 dB (7.9 mV), re 1V at 1 Pa
Signal-to-Noise Ratio
69 dB, 1 kHz at 1 Pa
Connectivity
Maximum Input Sound Level
150 dB SPL, 1 kHz at 1% T.H.D.
Output Connector
Integral 3-pin XLRM-type
Shipping
Weight
152 g (5.4 oz)
General
Transducer Type
Ribbon
Noise
25 dB SPL
Dynamic Range
125 dB, 1 kHz at Max SPL
