Specifications
Dimensions
Dimensions
Microphone: 25.0 mm (0.98") long, 10.2 mm (0.40") diameter; Power Module: 84 mm (3.31") H x 63 mm (2.48") W x 22 mm (0.87") D; Microphone: 25 mm (0.98") long, 10.2 mm (0.4") diameter
Weight
Weight (Microphone)
2.8 g (0.1 oz)
Weight (Power Module)
139 g (4.9 oz)
Electrical
Phantom
200Ω
Battery
270Ω
Open Circuit Sensitivity Phantom
-44 dB (6.3 mV) re 1V at 1 Pa
Phantom Power Requirements
11-52V DC, 2 mA typical
Battery Current/Life
0.4 mA / 1200 hours typical (alkaline)
Audio
Polar Pattern
Omnidirectional
Frequency Response
30 Hz - 20 kHz
Signal-to-Noise Ratio
66 dB, 1 kHz at 1 Pa
Connectivity
Output Connector (Power Module)
Integral 3-pin XLRM-type
Output Connector
Integral 3-pin XLRM-type (on Power Module)
Construction
Cable
1.8 m (6') long (permanently attached to microphone), 2.6 mm (0.10") diameter, 2-conductor, shielded cable with TA3F-type connector
Shipping
Weight
Microphone : 2.8 g (0.1 oz) - Power Module : 139 g (4.9 oz)
General
Transducer Type
Condenser
Low Frequency Roll Off
80 Hz, 18 dB/octave
Switches
Off, on-flat, on-roll-off
Power
Battery Type
1.5V AA/UM3
