Specifications
Dimensions
Dimensions
175 mm (6.89") long, 21 mm (0.83") diameter
Weight
Weight (less accessories)
80 g (2.8 oz)
Audio
Polar Pattern
Line + gradient
Frequency Response
90 Hz - 20 kHz
Output Impedance
100 ohms
Sensitivity
-30 dBV/Pa (31.6 mV)
Signal-to-Noise Ratio (Typical, A-weighted, Using Audio Precision System One)
1 74 dB, 1 kHz at 1 Pa* (*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL)
Phantom Power
11-52V DC, 2 mA typical
Connectivity
Maximum Input Sound Level
127 dB SPL, 1 kHz at 1% T.H.D.
Connector
3-Pin XLRM
General
Transducer Type
Condenser
Dynamic Range
(typical) 107 dB, 1 kHz at Max SPL
