Specifications
Antenna & Distribution
Antenna Power (optional)
12V DC, 250 mA max.
Current Consumption
200 mA ± 50 mA at 12 V DC
Gain
+1.0dB typical (within specified bandwidth)
Input
2 x 1 inputs
OIP3
+30dBm typical (within specified bandwidth)
Output
2 x 4 outputs + 1 cascade output
Termination Type
BNC Female
Operating Bandwidth
470-950 MHz
Power Supply
100-240V AC (50/60 Hz) to 12V DC 1A (centre positive) switched mode external power supply
Dimensions
420 x 180 x 144 mm
Weight
1.5 kg
Accessories
PSU, rack ears (short), BNC cable x8
