Specifications
Dimensions
Dimensions
210 mm (8.3")×191 mm (7.5")×43.4 mm (1.7") (W×D×H)
Audio
Frequency Response
40 Hz to 14,100 Hz
Total Harmonic Distortion
<0.2% (at 1 kHz, +4dBu input)
Maximum Input Level
XLR-F type: +24 dBu (at 0 dB sensitivity)
Connectivity
Input Connection
XLR-F type×2 (Pin1: GND
Output Connection
6.3 mm (1/4") TRS×2 (Tip: Hot
Network
100BASE-T
Network Port
RJ-45
Antenna Output
BNC-type, 50 ohms
Shipping
Weight
1,100 g (39 oz) (without accessories)
General
Operating Frequencies
Band DF2: 470.125 to 607.875 MHz
Minimum Frequency Step
25 kHz
Modulation Mode
FM
Nominal/Peak Deviation
±34 kHz nominal / ±45 kHz peak
Stereo Separation
75 dB
Operating Range
90 m (300') (Open range environment with no interfering signals)
Dynamic Range
>90 dB, A-weighted, typical
Maximum Simultaneous Use (recommended)
49 ch per band
IEM Transmitter
RF Output Power
Pin2
Hot
Pin3
Cold)
Ring
Cold
Sleeve
Ground)
Power Supply
100 to 240 V AC (50/60 Hz) to 12V DC 1 A (center positive) switched mode external power supply
