Specifications
Dimensions
Dimensions
186 mm (7.32") long, 47.6 mm (1.87") head diameter 21 mm (0.83") body diameter
Electrical
Phantom Power Requirements
11-52V DC, 7 mA typical (both channels total) Switches Flat, roll-off; 10 dB pad (nominal)
Audio
Polar Pattern
X/Y Stereo
Frequency Response
20 Hz - 17 kHz
Output Impedance
170 ohms
Sensitivity
-32 dBV/PA (25.1 mV)
Signal-to-Noise Ratio
80 dB, 1 kHz at 1 Pa
Connectivity
Maximum Input Sound Level
145 dB SPL, 1 kHz at 1% THD, 155 dB SPL, with 10 dB pad (nominal)
Connector
5-Pin XLRM
Construction
Cable
5 m (16.5') long, 8 conductor, shielded, vinyl-jacketed stereo cable with 5-pin XLRF-type connector at microphone end and two 3-pin XLRM-type connectors at output end
Shipping
Weight
269 g (9.5 oz)
General
Transducer Type
Condenser
Low Frequency Roll Off
80 Hz, 12 dB/octave
Channel Balance
<2.5 dB
Dynamic Range
131 dB, 1 kHz at Max SPL
