Specifications
Dimensions
Dimensions
236 mm (9.29") long, 21 mm (0.83") diameter
Electrical
Phantom Power Requirements
11-52V DC, 4 mA typical at 48V, each channel
Audio
Polar Pattern
Line-cardioid, Figure-of-eight
Frequency Response
40 Hz - 20 kHz
Output Impedance
200Ω
Connectivity
Output Connector
Integral XLR5M-type
Construction
Cable
Dual 0.61 m (24") shielded two-conductor, terminated in two XLR3M-type connectors
Shipping
Weight
103 g (3.6 oz)
General
Transducer Type
Condenser
Low Frequency Roll Off
80 Hz, 12 dB/octave
Mid
-30 dB (31.6 mV) re 1V at 1 Pa;
Side
-34 dB (19.9 mV) re 1V at 1 Pa;
LR Stereo
-36 dB (15.8 mV) re 1V at 1 Pa
Switches
M-S, LR Stereo-Wide (LR-W), LR Stereo-Narrow (LR-N), Flat, roll-off
