Specifications
Dimensions
Maximum Body Diameter
40 mm (1.6")
Height
10.5 mm (0.41")
Cable Length
20 m (66')
Weight
Microphone Weight (Excluding Cable)
80 g (2.8 oz)
Microphone Weight (Including Cable)
412 g (15 oz)
Electrical
Phantom Power Requirements
20 to 52 V DC, 3 mA
Audio
Element
Piezoelectric
Frequency Response
20 to 4,000 Hz
Open Circuit Sensitivity
-20 dBV/G (100 mV/G) (at 500 Hz)
Impedance
60 ohms
Connectivity
Output Connector
3-pin XLR-M type
Construction
Body Material
Dezincification-resistant (DZR) brass
Through Holes
4
Threaded Mounting Hole
1/4"
Environmental
Waterproof Performance
Equivalent to IPX7
Operation Temperature Range
-20°C (-4°F) to 60°C (140°F)
Storage Temperature Range
-20°C (-4°F) to 60°C (140°F), 10% to 90% RH (without condensation)
Shipping
Package Weight
1.29 lbs
Package Width
7.2"
Package Length
7.2"
Package Height
2.4"
