Specifications
Weight
Weight (Microphone)
Microphone, boom & earpiece: 2.6 g (0.09 oz)
Weight (Power Module)
85 g (3.0 oz) (wired only)
Electrical
Phantom Power Requirements
11-52V DC, 2 mA typical (wired only)
Voltage Range
2.5-10V (wireless only)
Audio
Polar Pattern
Omnidirectional
Frequency Response
20 Hz - 20 kHz
Output Impedance
250Ω (wired only)
Open Circuit Sensitivity
-43 dB (7.2 mV) re 1V at 1 Pa
Signal-to-Noise Ratio
63 dB, 1 kHz at 1 Pa
Microphone
0.37 inch (9.5 mm) long, 0.1 inch (2.6 mm) diameter
Connectivity
Maximum Input Sound Level
136 dB SPL, 1 kHz at 3% T.H.D.
Output Connector (Power Module)
Integral 3-pin XLRM-type (wired only)
Cable Detachable
55 inches (1.4 m) long, 0.06 inch (1.6 mm) diameter, 2- or 3-conductor shielded cable (termination dependent)
General
Transducer Type
Condenser
Low Frequency Roll Off
80 Hz, 18 dB/octave (wired only)
Dynamic Range
104 dB, 1 kHz at Max SPL (wired only)
Switches
Flat, roll-off (wired only)
Current Consumption
0.2 mA typical at 5V (wireless only)
Boom
3.88 inches (98.5 mm) long, 0.04 inch (1.07 mm) diameter
Power Module
3.94 inches (100 mm) long, 0.74 inch (18.9 mm) diameter (wired only)
