Specifications
Electrical
Voltage Range
1.5-9V
Audio
Polar Pattern
Omnidirectional
Frequency Response
20 Hz - 20 kHz
Open Circuit Sensitivity
–45 dB (5.6 mV) re 1V at 1 Pa
Signal-to-noise Ratio (1 Pascal = 10 dynes/cm2 = 10 Microbars = 94 Db SPL)
60 dB, 1 kHz at 1 Pa
Microphone
21.7 mm (0.85") long, 9.2 mm (0.36") diameter
Connectivity
Meximum Input Sound Level
116 dB SPL, 1 kHz at 1% T.H.D.
Microphone, Boom, Connector & Cable
24 g (0.84 oz)
Construction
Cable
1.4 m (55") terminated with locking 4-pin connector for use with A-T UniPak® body-pack transmitters
General
Transducer Type
Condenser
Current Consumption
0.3 mA typical at 5V
Microphone & Boom
4 g (0.14 oz)
Boom
110.0 mm (4.33") long, 2.4 mm (0.09") boom diameter
