Specifications
Dimensions
Dimensions
0.91" (23 mm) H x 3.30" (83.9 mm) W x 4.25" (108 mm) D
Electrical
Phantom Power Requirements
11-52V DC, 9.3 mA
Audio
Polar Pattern
Cardioid
Frequency Response
20 Hz - 20 kHz
Output Impedance
50 ohms
Sensitivity
-34 dBV/Pa (19.9 mV)
Signal-to-Noise Ratio
68 dB, 1 kHz at 1 Pa, A-weighted
Microphone
TB3M-type
Connectivity
Maximum Input Sound Level
130 dB SPL, 1 kHz at 1% T.H.D.
Construction
LED Color
mic on, mic off
Cable
25 foot (7.6 m) long, 0.13" (3.2 mm) diameter, 5-conductor shielded cable (2 conductors under shield; 3 control wires outside shield); TA5F-type connector at microphone end, output end stripped and tinned for connection to electronic device
Shipping
Weight
253 g (8.9 oz)
General
Transducer Type
Condenser
Low Frequency Roll Off
80 Hz, 18 dB/octave
Dynamic Range
104 dB, 1 kHz at Max SPL
Activation
on/off
Switch Function
touch on/off, momentary on, momentary off
Control
local, remote, LED remote
Switches
Flat, roll-off
