Specifications
Electrical
Power Requirements
None
Audio
Frequency Response
30 Hz – 15 kHz
Polar Pattern
Cardioid
Output Impedance
280 ohms
Sensitivity
0.8 mV / Pa @ 1k
Connectivity
Connector
3-pin XLRm
Construction
Materials / Finish
Machined Aluminum / Black Finish
Shipping
Weight
254 g / 8.9oz
Identifiers
Length
117 mm / 4.6 in
General
D6 Kick Drum Microphone
VLM Capsule, 5 year warranty
Transducer Type
Dynamic
Capsule Technology
WLM Type E
Off-Axis Rejection
>20 dB
Maximum SPL
=144 dB
Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
D2 Rack Tom Microphone
VLM Capsule, 5 year warranty
i5 Dynamic Instrument Microphone
VLM Capsule, 5-year warranty
SCX1C Condenser Microphone
Professional, studio quality cardioid condenser, Extremely sensitive with pin-point accuracy, 21 mm gold vapor capsule with modular design, 3 year warranty
SCX1HC Condenser Microphone
Professional, studio quality cardioid condenser, Extremely sensitive with pin-point accuracy, 21 mm gold vapor capsule with modular design, 3 year warranty
