Specifications
Electrical
Power Requirements
12-48 V Phantom
Audio
Polar Pattern
Cardioid
Frequency Response
40 Hz - 20 kHz
Output Impedance
200 ohms
Sensitivity
8 mV / Pa @ 1k
Signal to Noise Ratio
69 dB
Construction
Materials / Finish
Zinc Alloy / Black Finish
Shipping
Weight
3.3 oz (95 g)
Identifiers
Length
4.37 inches (111 mm)
General
Transducer Type
Condenser
Capsule Technology
Gold Vapor Deposition
Equivalent Noise Level
25 dB (A-weighted)
Off-Axis Rejection
>24 dB
Maximum SPL
≥137 dB
Dynamic Range
112dB
Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
