Specifications
Electrical
Power Requirements
None
Audio
Frequency Response
52 Hz – 15 kHz
Polar Pattern
Hypercardioid
Output Impedance
580 ohms
Sensitivity
2 mV / Pa @ 1k
Connectivity
Connector
3-pin XLRm
Construction
Materials / Finish
Zinc Alloy / Black Finish
Shipping
Weight
8 oz (247 g)
Identifiers
Length
4.09 inches (104 mm)
General
Transducer Type
Dynamic
Capsule Technology
LM Type A
Off-Axis Rejection
>20 dB
Maximum SPL
=139 dB
Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
f2 Microphone
3 year warranty
f5 Microphone
3 year warranty
f6 Microphone
3-year warranty
