Specifications
Electrical
Power Requirements
9-48 V Phantom Power
Audio
Frequency Response
40Hz - 20,000Hz
Polar Pattern
cardioid
Output Impedance
200 Ω
Sensitivity
6 mV (C) / Pa @ 1k 8 mV (O) / Pa @ 1k
Signal to Noise Ratio
> 63 / 64 dB
Max. SPL
130 dB
Connectivity
Cable / Connector
Shielded 3’ (L5) terminating to a miniature 3 pin XLRf connector
Shipping
Weight
0.47 oz
Identifiers
Length
0.91"
General
Transducer Type
pre-polarized condenser
Equivalent Noise Level
< 31 / 30 dB (A-Weighted)
Dynamic Range
99 dB / 130 dB
Polarity
positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
