Specifications
Electrical
Power Requirements
48-52 V
Audio
Polar Pattern
Cardioid
Frequency Response
40 Hz - 20 kHz
Output Impedance
250 ohms
Sensitivity
VX10 – 24 mV / Pa @ 1k VX10LO – 4 mV / Pa @ 1k
Signal to Noise Ratio
75 dB
Connectivity
Connector
3-pin XLRm
Construction
Materials / Finish
Zinc Alloy & Machined Brass / Black Finish
Shipping
Weight
310 g / 10.9 oz
Identifiers
Length
180 mm / 7.1 in
General
Transducer Type
Condenser
Equivalent Noise Level
19 dB (A-weighted)
Off Axis Rejection
>20 dB
Maximum SPL
≥138 dB (w/ -10 pad)
Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
