Audio-Technica ATV-SG1LE On-Camera Shotgun Mic

Audio-Technica ATV-SG1LE On-Camera Shotgun Mic

SoundPro Item: 203803 | Part Number: ATV-SG1LE

$119.00
$140.00 $119.00
Your Price Sold out
MSRP: $140.00 | MAP: $119.00

Usually ships in 5-7 business days

  • 14 mm diaphragm supports detailed sound capture
  • 100 mm acoustic tube reduces background pickup
  • Shock mount helps limit camera vibration noise
  • Noise-immunity design resists hum and RF noise
  • 30-degree rotation aids off-center placement
  • Plug-in power operation requires no batteries
Log in or register for YOUR best price

The Audio-Technica ATV-SG1LE is a compact on-camera shotgun microphone built for content creation and broadcast-style capture where controlled directional pickup is required. Its 100 mm acoustic tube helps concentrate on the intended source while reducing ambient distractions.

A 14 mm large-diameter diaphragm supports detailed, natural audio reproduction, while the integrated shock mount helps reduce noise from camera movement and vibration. Plug-in power operation eliminates the need for batteries, and the included wind muff supports clearer outdoor recording.

View full details

Specifications

Microphone
Element
Fixed-charge back plate, permanently polarized condenser
Polar Pattern
Line + gradient
Frequency Response
20-20,000 Hz
Open Circuit Sensitivity
-38 dBV
Maximum Input Sound Level
114 dB SPL (1 kHz, THD 3%)
Dynamic Range
102.5 dB (1 kHz at Max SPL)
Signal-to-Noise Ratio
82.5 dB (1 kHz at 1 Pa, A-weighted)
Power Supply
Plug-in power (1.5 V to 5.0 V)
Main Output Terminal
3.5 mm (1/8"") stereo mini-jack
Environmental
Operation Temperature Range
0°C to 40°C (32°F to 104°F)
Storage Temperature Range
10°C (14°F) to 60°C (140°F), 10% to 90% RH (without condensation)
Physical
Weight
About 100 g (3.5 oz)
Dimensions
127.1 mm (5.0”) long 35 mm (1.4”) maximum body diameter (microphone) 59 mm (2.3”) height
Accessories Included
Accessories Included
Coiled cable (approx. 5 cm (2.0”) (when extended: approx. 50 cm(20”)), 3.5 mm (1/8"") stereo mini plug × 2); Wind muff (exclusive for ATV-SG1LE)
