Audio-Technica ATW-1421/L System 20 PRO Dual Lavalier Microphone System

Audio-Technica ATW-1421/L System 20 PRO Dual Lavalier Microphone System

SoundPro Item: 201590 | Part Number: ATW-1421/L

$1,249.00
$1,749.00 $1,249.00
Your Price Sold out
MSRP: $1,749.00 | MAP: $1,249.00

Usually ships in 5-7 business days

  • 24-Bit/48 kHz Digital Audio Delivers Studio-Grade Fidelity Over Wireless
  • 2.4 GHz Operation Eliminates TV Interference And Frequency Coordination
  • Switchable Standard/HD Modes Balance Latency Against Channel Capacity
  • True Diversity Antenna Design Ensures Consistent Coverage Across Venues
  • Remote Receiver Mounting Up To 328 Feet Enables Flexible System Architecture
  • AES128 Encryption Protects Against Unauthorized Transmission Interception
  • Wireless Manager Software Provides Centralized Monitoring And Configuration
Log in or register for YOUR best price

The Audio-Technica System 20 PRO is engineered for live production, theater, corporate events, and broadcast applications where dual talent miking demands rock-solid wireless performance. The ATW-1421/L ships as a complete dual-lavalier system with two bodypack transmitters, two lavalier microphones, a single receiver chassis, and all necessary mounting and charging accessories. This system operates in the unregulated 2.4 GHz ISM band, eliminating frequency coordination complexity and TV interference concerns.

Sound professionals choose this system for its flexible channel architecture: Standard mode provides 10 simultaneous channels with minimal 2.8ms latency, while HD mode delivers 20 channels at 6.7ms latency. The receiver chassis docks into your equipment rack or mounts remotely up to 328 feet away via Ethernet, accommodating complex venue layouts. True diversity antenna design and AES128 encryption ensure reliable, secure signal transmission. Each receiver channel pairs with up to four transmitters, so talent can swap between bodypack and handheld configurations mid-show without re-tuning.

The system integrates with Audio-Technica's Wireless Manager software for centralized monitoring of RF signal strength, battery status, and system health across all linked units. OLED displays on transmitters and receivers provide at-a-glance confirmation of mode, channel, and power status, critical for fast-paced production environments.

Downloads

View full details

Specifications

Operating Frequencies
Frequency Range
2,402 to 2,480 MHz
Audio Performance
Audio Sampling Rate
24-bit/48 kHz
Frequency Response
20 to 20,000 Hz
Dynamic Range
120 dB (A-weighted)
Total Harmonic Distortion
< 0.05%
Channel Configuration
Standard Mode Channels
10
HD Mode Channels
20
Standard Mode Latency
2.8ms
HD Mode Latency
6.7ms
Security & Control
Encryption Method
AES128
Remote Receiver Distance
328 feet
Maximum Linked Chassis
5
Transmitters Per Channel
4
Receiver Chassis (ATW-R1440)
Dimensions
8.3" x 6.5" x 1.7"
Weight
26 oz
Power Supply
12 V DC, 0.5 A
Power Consumption
3.7W
Operating Temperature
0°C to 40°C
Output Level (Line Maximum)
+22 dBu
Output Level (Mic Maximum)
−12 dBu
External Receiver Unit (ATW-RU14)
Dimensions
3.4" x 2.8" x 0.74"
Weight
2.7 oz
RF Output Power
10mW EIRP
RF Sensitivity
−90 dBm
Antenna
1/2 wave dipole antenna, true diversity
Operating Temperature
0°C to 40°C
Bodypack Transmitter (ATW-T1401)
Dimensions
2.5" x 0.89" x 4.2"
Weight
2.8 oz (without batteries)
Battery
Two 1.5 V AA
Battery Life (Alkaline)
Approx. 15 hours
Battery Life (Nickel-Hydrogen)
Approx. 14.5 hours
Battery Life (Lithium)
Approx. 29 hours
RF Output Power
10mW EIRP
RF Sensitivity
−90 dBm
Operating Temperature
5°C to 40°C
Input Connector
Four-pin locking (cW-style)
Included Accessories
Receiver
AC adapter, AC adapter blade, short and long rack-mount adapters, fixing screws, link cable (12"), legs
External Receiver Unit
Unit holder, holder cover, wood screws, antennas
