Bag End TA80T-IY 8" 2-Way Horn Loaded Install Speaker With Yoke
Bag End TA80T-IY 8" 2-Way Horn Loaded Install Speaker With Yoke
SoundPro Item: 207139 | Part Number: TA80T-IY
Usually ships in 5-7 business days
- Time-Align Passive Crossover Ensures Coherent Driver Arrival For Clear Speech Intelligibility
- Conical High Frequency Waveguide Produces Uniform Horizontal And Vertical Coverage
- Half-Trapezoidal Cabinet Allows Close Ceiling Mounting While Preserving Bass Response
- Included Steel Yoke U-Bracket Supports Vertical Or Horizontal Mounting Without Extra Hardware
- Optional 70/100/140V Internal Transformer Enables Direct Connection To Commercial Distribution Systems
- Optional Self-Powered And Custom Finish Configurations Available For Flexible Integration
The Bag End TA80T-IY is a compact, horn-loaded 2-way installation loudspeaker built for integrators and system designers who need consistent, high-output coverage in mid-field and near-field positions. Its half-trapezoidal enclosure allows close ceiling mounting with a downward angle while preserving cabinet volume for solid upper bass extension — a practical advantage in under-balcony, delay, and front-fill applications where physical clearance is limited and pattern control matters.
At its core, the TA80T-IY pairs an 8" low-frequency driver with a 1" exit compression driver running through a hybrid conical waveguide and a passive Time-Align crossover at 2.8 kHz. The Time-Align topology aligns driver arrival times to within ±25 microseconds, which translates to coherent transient response and intelligible speech reproduction — critical for houses of worship, auditoriums, fitness centers, and AV presentation rooms where clarity across seating zones is non-negotiable.
The included steel yoke U-bracket supports both vertical and horizontal mounting orientations, giving installers flexibility during rigging without requiring additional hardware. For system designers building larger arrays, the TA80T-IY integrates cleanly with Bag End subwoofers to extend low-frequency capability, and optional 70/100/140V transformer and custom finish options make it adaptable to commercial distribution systems and branded environments alike.
Specifications
