Behringer WING Rack 48-Channel Digital Mixing Engine with 24 Midas PRO Preamps

Behringer WING Rack 48-Channel Digital Mixing Engine with 24 Midas PRO Preamps

SoundPro Item: 151861 | Part Number: Wing Rack

$1,799.00
$1,799.00 $1,799.00
Your Price Sold out
MSRP: $1,799.00 | MAP: $1,799.00

Usually ships in 5-7 business days

  • 48-Channel Digital Mixing Engine – Rackmount mixer with 28 stereo buses and flexible mono, stereo, or M/S channel configuration.
  • 24 Midas PRO Microphone Preamps – Delivers legendary Midas sound quality with high headroom and wide dynamic range.
  • 10.1" Touchscreen Interface – Intuitive control with rotary encoders and customizable control layers for fast operation.
  • Over 80 Built-In Effects – Includes classic hardware emulations such as Pultec EQ, LA-2A, 1176, SSL Bus Compressor, and more.
  • Integrated Multitrack Recording – Record up to 64 channels simultaneously using the included WING LIVE dual SD card recorder.
  • Extensive Digital Connectivity – AES50, USB, AoIP, and StageConnect provide flexible system integration and expansion.
  • Expandable Networking Options – Supports optional expansion cards for Dante, Waves SoundGrid, and other audio networking formats.
Log in or register for YOUR best price

The Behringer WING Rack is a powerful rackmount digital mixing engine designed for professional live sound and studio applications. It features a 48-channel, 28-bus full stereo architecture with 24 renowned Midas PRO microphone preamps, delivering exceptional sound quality and dynamic range in a compact format.

A 10.1" touchscreen and customizable control panel provide intuitive operation, while flexible channel configuration allows mono, stereo, or mid/side operation without reducing channel count. With extensive digital I/O, built-in effects, and powerful routing, WING Rack delivers a complete mixing ecosystem for modern production environments.

View full details

Specifications

MIXING ENGINE
Channels
48 digital mixing channels
Buses
28 stereo buses
Channel Configuration
Mono; Stereo; Mid/Side
Internal Processing
40-bit floating point processing
PREAMPS & OUTPUTS
Microphone Preamps
24 Midas PRO mic preamps
Outputs
8 Midas PRO outputs
DISPLAY & CONTROL
Touchscreen
10.1" color touchscreen
Control Interface
Swivel front control panel; rotary encoders; customizable control layers
EFFECTS
Effects
80+ built-in effects and classic hardware emulations
Effect Engines
Multiple insert points and FX slots
RECORDING
Multitrack Recording
Up to 64 channels simultaneous recording
Media
Dual SD card slots via WING LIVE card
CONNECTIVITY
Digital I/O
AES50; USB; AoIP; StageConnect
Expansion Slots
Supports optional Dante; MADI; Waves SoundGrid cards
StageConnect
32 channels of 24-bit audio over single XLR/DMX cable
I/O CAPACITY
Total Inputs
Up to 382 inputs
Total Outputs
Up to 368 outputs
FORM FACTOR
Type
Rackmount digital mixer
Control Panel
Swivel front panel with dedicated custom control section
