Specifications
Dimensions
Dimensions Without Connector (L X W X H)
90 x 86 x 27 mmWeight: 413 g
Electrical
Noise Voltage
1.1 µV [A, RMS], 4.9 µV [CCIR, Q-Peak]
Power Supply: Phantom Power
P48 (+48 VDC ±4 VDC, 6.8 kΩ ±20%, current consumption: < 3.2 mA), P24 (+24 VDC ±4 VDC, 1.2 kΩ ±20%, current consumption: < 3.2 mA), P12 (+12 VDC ±4 VDC, 680 Ω ±20%, current consumption: < 3.2 mA)
Audio
Polar Pattern
Half-cardioid
Frequency Response
25 Hz - 20 kHz
Output Impedance
< 200 ohms
Sensitivity
1.5 mV/Pa (-56 dBV)
Max. SPL at 1 Khz
148 dB [SPL@1% THD]
Signal-to-noise Ratio
63 dB [A, RMS], 50 dB [CCIR, Q-Peak]
A-weighted Equivalent SPL
31.2 dB
Connectivity
Connector
3-Pin XLRM
General
Transducer Type
Condenser
