Specifications
Dimensions
Gooseneck Length
72 mm
Electrical
Load Impedance
≥ 1 kohms
Open Circuit Voltage
5 mV/Pa (-46 dBV) ±2.5 dB
Max. SPL at 24 V and 48 V Phantom Power
140 dB
Audio
Polar Pattern
Cardioid
Frequency Response
20 Hz - 20 kHz
Output Impedance
200 ohms
Equivalent SPL
35 dB [CCIR; Q-Peak]; 24 dB [A; RMS]
Connectivity
Connector
3-pin XLR male
Shipping
Weight
approx. 145 g
General
Transducer Type
Condenser
S/N Ratio
59 dB [CCIR; Q-Peak]; 70 dB [A; RMS]
Power Supply
Phantom power: 12 - 48 V (recommended: 48 V)
Clamp (W X H)
85 x 118 mm
