Specifications
Certifications
Compliance
UL1480, UL2043, CSA62368-1, NFPA70, NFPA90
Zoom Certification
Yes
Dimensions
Diameter
13.43"
Depth
8.51"
Cutout Diameter
12.20"
Weight
Weight
15.6 lbs
Audio
Loudspeaker Type
Two-way coaxial ceiling loudspeaker
Operating Range
75 Hz - 20 kHz
Impedance
7Ω
Sensitivity (1W/1m)
93 dB
Maximum Output @1m
116 dB
Peak Output
126 dB
Dispersion
115° conical
LF Driver
1 x 8"
HF Driver
1 x 1.25" compression driver
Electrical
Power Handling
175W Continuous, 700W Peak
70V Transformer Taps
120W, 60W, 30W, 15W
100V Transformer Taps
120W, 60W, 30W
Construction
Finish
White RAL 9016
Operating Environment
Indoor
