Specifications
Certifications
Microsoft Teams Certified
Yes
Zoom Certified
Yes
Barco Certified
Yes
FCC Part 15B
Yes
CE Marked
Yes
UL and C-UL Listed
Yes
RoHS Compliant
Yes
Dimensions
Height
3.9"
Width
37"
Depth
2.5"
Weight
Weight
9.6 lbs
Power
USB-C Power
60W
External Power Supply
100-240VAC 50/60Hz (12VDC, 4.74A)
Audio
Microphone Technology
27-Element Digital Array
Polar Pattern
Active Beamformed
Microphone Sensitivity
> -37dBFS ± 1dB
Microphone Frequency Response
(100 Hz - 8 kHz): -10dB
Microphone SNR
(@ 1kHz, 94dB SPL, A-Weighted): 69 dB
Microphone Maximum SPL
(@ 1kHz, THD < 10%): 130 dB
Pickup Range
(25dBA noise floor): > 23 feet (7 m)
Microphone Data Rate Output
48 kHz
Audio Processing
AEC (Acoustic Echo Cancellation), AI Filter Noise Reduction
Loudspeaker Transducers
2x 2.5" (60 mm) full range
Loudspeaker Sensitivity
(@ 1m, 2.83V): 84 dB
Loudspeaker Frequency Response
(57 Hz - 20 kHz): -10 dB
Loudspeaker Rated Maximum SPL
(@ 1m): 90 dB (continuous), 96 dB (peak)
Nominal Impedance
4Ω
Continuous Rated Power
(6 dB crest factor, HPF @ 60 Hz): 20W
THD
(@ 1kHz): < 0.2%
Sampling Rate
48 kHz
Nominal Beamwidth
(H x V): 180° x 180°
Video
Image Sensor
12 Megapixel
Supported Resolutions
720p @ 30fps, 1080p @ 30fps, 2160p @ 30fps
Diagonal Field of View
120 Degrees
Horizontal Field of View
109 Degrees
Vertical Field of View
75 Degrees
Focus Distance
100 cm
Digital Zoom
5x
Positioning
Autoframing, Electronic Pan/Tilt/Zoom, UVC controlled
Lens Cap
Automated Privacy Shutter
Camera Active Indicator
White/Off LED
Connectivity
USB 3.0
1x Type C
Assistive Listening Feed
1x 3.5mm mono balanced
Environmental
Ambient Operating Temperature Range
32 - 104° F (0 - 40° C)
Humidity
0-90% (non-condensing)
Altitude
0-10,000 ft (0-3000m) MSL
