Specifications
Certifications
TAA Compliant
Yes
Compliance
FCC Part 15B, UL, C-UL, CE, RoHS
Dimensions
Height
1.8"
Width
11.2"
Depth
6.9"
Weight
Weight
2.0 lbs
Power
Power
24V DC 60W
Audio
USB Bit Depth
24-bit
USB Sample Rate
48 kHz
Frequency Response (Line Out)
+0/-0.25 dB (20 Hz - 20 kHz)
THD+N (Line Out)
< 0.005% (20 Hz - 10 kHz)
Dynamic Range (Line Out)
107 dB A-Weighted
D/A Converters
24-bit
Amplifier
Channels
1
Continuous Power Output
20 W (THD+N < 0.025%)
Frequency Response (Amp)
+0.2/-0.5 dB (20 Hz - 20 kHz)
THD+N (Amp)
< 0.03% (1 kHz, 1 W)
Dynamic Range (Amp)
100 dB A-Weighted
Minimum Load Impedance
4Ω
Intermodulation Distortion
< 0.07% (SMPTE)
Connectivity
USB Audio
Yes (Windows/Mac driverless)
USB Device Charging
Up to 5 W
Network
RJ-45 Ethernet (Cat 5e or higher)
Analog Audio Output
RCA
HDMI Audio Formats
2ch L-PCM, 44.1/48 kHz, 16-bit
Bluetooth Version
4.2 Class 2
Bluetooth Profiles
HFP 1.7, AVRCP 1.6, A2DP 1.3
Bluetooth Codecs
CVSD (8 kHz), mSBC (16 kHz), SBC (44.1/48 kHz)
Bluetooth Range
Up to 100 feet (30 m)
Video
Supported Resolutions
640x480p (60 Hz), 720x480p (60 Hz), 720x576p (50 Hz), 1280x720p (50/60 Hz), 1920x1080p (50/60 Hz), 3840x2160p (30 Hz)
HDCP Support
1.4
Physical Video Interface
HDMI
Controls
Front Panel Indicators
Mic Status (Green/Red), Room Tuning (Green/Red), Power/Wireless (Green/Red/Blue)
Environmental
Operating Temperature
32-104° F (0-40° C)
Humidity
0-95% relative humidity (non-condensing)
Altitude
0-6,600 ft (0-2000 m) MSL
Included Items
Bundle Contents
Devio SCR-25 hub, Devio DTM-1 tabletop microphone, under-table mounting bracket
Warranty
5 years
