Blackmagic Design BMD-BDLKWEB/D/SED4K 4K H.265 SRT Streaming Encoder

Blackmagic Design BMD-BDLKWEB/D/SED4K 4K H.265 SRT Streaming Encoder

SoundPro Item: 151778 | Part Number: BMD-BDLKWEB/D/SED4K

$765.00
$765.00 $765.00
Your Price Sold out
MSRP: $765.00 | MAP: $765.00

Usually ships in 5-7 business days

  • Dual-Codec H.264 And H.265 Engine Covers HD Through Ultra HD Streaming Formats
  • SRT And RTMP Protocol Support Enables Secure Or Platform-Direct Live Delivery
  • USB Tethering To 5G Or 4G Phones Provides Mobile Network Streaming Redundancy
  • Dual USB-C Webcam Outputs Appear As UVC Devices In Any Compatible Software
  • CEA-608 And CEA-708 Closed Caption Embedding Supports Broadcast Compliance Over RTMP
  • HDR Metadata Pass-Through Preserves HLG And ST2084 Grading In Live Streams
  • Front Panel LCD With Spin Knob Allows On-Device Control Without An External Computer
Log in or register for YOUR best price

The Blackmagic Design Streaming Encoder 4K is engineered for broadcast engineers, live production teams, and AV integrators who need a dedicated, rack-mountable streaming solution without relying on a host computer. Accepting 12G-SDI signals with automatic standards conversion, it ingests virtually any HD or Ultra HD camera feed and encodes it in H.264 or H.265 at resolutions up to 2160p60, streaming directly over RTMP or SRT to YouTube, Facebook, Twitch, Vimeo, Restream, and dozens of additional platforms.

In live production environments where network conditions are unpredictable, the dual-path connectivity is a practical advantage: operators can route the stream over a wired Ethernet connection or tether a 5G or 4G smartphone via USB to use mobile data as a failover or primary path. Two USB-C webcam outputs at up to 2160p60 allow the unit to appear as a UVC device in any compatible software — Zoom, OBS Studio, Microsoft Teams, Wirecast, and more — without additional capture hardware.

For technical monitoring, dedicated SDI and HDMI outputs deliver 1080p reference feeds to confidence monitors or scopes, while the built-in 2.2-inch LCD and six-button front panel with spin knob allow on-device control without a laptop. CEA-608 and CEA-708 closed caption pass-through over RTMP, HDR metadata support including HLG and multiple ST2084 levels, and source timecode embedding over both RTMP and SRT make this encoder appropriate for broadcast-grade productions where compliance and metadata integrity are non-negotiable. The one-third rack unit width and 1U height simplify integration into existing fly packs and production racks.

Downloads

View full details

Specifications

Connectivity
SDI Video Inputs
1
SDI Loop Outputs
1
SDI Monitor Outputs
1
SDI Rates
1.5G, 3G, 6G, 12G
HDMI Monitor Outputs
1
SDI Audio Inputs
16 channels embedded audio
SDI Audio Outputs
16 channels embedded audio on Loop Out
HDMI Audio Outputs
2 channels embedded audio on Monitor Out
Webcam Output
1 x USB-C up to 2160p60
Ethernet
10/100/1000 BASE-T
Standards
HD Video Input Standards
720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Ultra HD Video Input Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
SDI Compliance
SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10, SMPTE 2084, SMPTE 2108-1
Video Input Color Space
Rec. 709, Rec. 2020
3G SDI
Auto detects SMPTE level A or B on SDI input
SDI And HDMI Monitor Out Video Standards
1080p50, 1080p59.94, 1080p60
Video Streaming Standards
720p25, 720p30, 720p50, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
HDR Metadata Support
Hybrid Log-Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084
Streaming
Streaming Protocols
RTMP (H.264), SRT (H.264 and H.265)
Closed Captions
CEA-608 and CEA-708 over RTMP
Timecode
Source timecode over RTMP and SRT
Compatible Services
Facebook, Twitch, YouTube, Twitter, Restream.IO, Vimeo, BoxCast, Castr, AfreecaTV, Bilibili, DouYu, Weibo, Zoom, Skype, Microsoft Teams, QuickTime Player, FaceTime, OBS Studio, Open Broadcaster, VLC, Wirecast Play, Wowza Streaming Engine
Controls
Control Panel
6 buttons, spin knob, 2.2" color LCD display
Device Control
Front panel, USB-C, or Ethernet
External Control
Remote camera control, color corrector, tally, talkback
Power
Power Supply
1 x Internal 100-240V AC
12V DC Input
1 x 4-pin XLR
Power Usage
25 W
Physical
Rack Format
One third rack unit width, 1 rack unit height
Operating Systems
Mac
Mac 13.0 Ventura, Mac 14.0 Sonoma or later
Windows
Windows 10 64-bit, Windows 11
Other OS
Linux, Chrome OS
Environmental
Operating Temperature
0° C to 40° C (32° to 104° F)
Storage Temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
Identifiers
Warranty
3-Year Limited Manufacturer's Warranty
