Specifications
Dimensions
Effective Sensor Size
18.96mm x 10mm (Four Thirds)
Screen Dimensions
5” 1920 x 1080
Optics
Focus
Auto focus available using compatible lenses
Iris Control
Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses
Construction
Lens Mount
Active MFT mount
Lens Control
Iris, focus and zoom on supported lenses
General
Dynamic Range
13 Stops
Dual Native ISO
400 and 3200
Shooting Resolutions
4096 x 2160 (4K DCI) up to 60 fps, 4096 x 1720 (4K 2.4:1) up to 75 fps, 3840 x 2160 (Ultra HD) up to 60 fps, 2880 x 2160 (2.8K Anamorphic) up to 80 fps, 2688 x 1512 (2.6K 16:9) up to 120 fps, 1920 x 1080 (HD) up to 120 fps
Frame Rates
Maximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported., Off-speed frame rates up to 60 fps in 4K DCI, 120 fps in 2.6K 16:9 and HD windowed.
Screen Type
LCD capacitive touchscreen
Metadata Support
Automatically populated lens data from electronic Micro Four Thirds lenses. Automatic recording of camera settings and slate data such as project, scene number, take and special notes.
Controls
Touchscreen menus on 5 inch screen, 1x Power Switch, 1x Record Button, 1x Stills Button, 1x Scroll Wheel with push integrated into handgrip, 1x ISO Button, 1x White Balance, 1x Shutter Button, 3x software configurable Fn buttons, 1x IRIS Button, 1x Focus Button, 1x High Frame Rate (HFR) Button, 1x Zoom Button, 1x Menu Button, 1x Playback Button
