Blackmagic Design BMD-CINSTUDMFT/G24PDDG2 4K Plus G2 Studio Camera

Blackmagic Design BMD-CINSTUDMFT/G24PDDG2 4K Plus G2 Studio Camera

SoundPro Item: 141066 | Part Number: BMD-CINSTUDMFT/G24PDDG2

$1,519.00
$1,519.00 $1,519.00
Your Price Sold out
MSRP: $1,519.00 | MAP: $1,519.00

Usually ships in 5-7 business days

  • Dual Native ISO Sensor Handles Challenging Lighting From Arenas To Low-Light Venues
  • 10G Ethernet Enables Low-Cost SMPTE Fiber-Style Network Camera Workflows
  • Built-In DaVinci YRGB Color Corrector Allows On-Camera Grade Without External Hardware
  • Blackmagic RAW Recording To External USB Media Preserves Full Dynamic Range For Post
  • ATEM Switcher Integration Via Blackmagic Control Protocol Supports Full Remote Camera Control
  • Live Tally And SDI Talkback On Channels 15 And 16 For Complete Multi-Camera Production
  • REST API Over USB Ethernet Enables Custom Remote Control Via HTTP Client Applications
Log in or register for YOUR best price

The Blackmagic Studio Camera 4K Plus G2 is engineered for broadcast engineers, live production directors, and systems integrators who need full-featured studio camera capability in a portable form factor. With an active MFT mount, 12G-SDI, 10G Ethernet for SMPTE fiber-style workflows, and a built-in color corrector using DaVinci YRGB color science, this camera delivers broadcast-grade image quality without requiring a large traditional studio camera chain. It is equally at home in a fixed install, a flypack production, or a multi-camera live concert rig.

The sensor's dual native ISO and 13 stops of dynamic range make it capable in high-contrast environments — from arena sports lighting to dimly lit worship spaces or conference rooms. Blackmagic RAW recording to external USB media via the USB-C expansion ports means operators can capture clean, high-latitude files alongside the live SDI output, giving post teams full flexibility. Talkback on SDI channels 15 and 16, live tally, and ATEM switcher integration via Blackmagic Control Protocol streamline multi-camera production without additional hardware.

The 7-inch HDR touchscreen display with physical dials for brightness, contrast, and peaking gives camera operators precise on-camera monitoring and control — critical when working without a separate monitor. Network management features including FTP, SMB file sharing, and a REST API over USB Ethernet make this camera a strong fit for modern IP-centric production environments where remote control and file retrieval are operational requirements.

Downloads

View full details

Specifications

Camera
Effective Sensor Size
17.78mm x 10mm (Four Thirds)
Lens Mount
Active MFT Mount
Lens Control
Iris, Focus, Zoom on Supported Lenses
Dynamic Range
13 Stops
Dual Native ISO
0dB and 18dB Gain
Sensitivity at 0dB Gain
f11 with 2160p59.94
Signal to Noise Ratio
63dB for 2160p
Shooting Resolution
3840 x 2160 (Ultra HD) up to 60 fps
Frame Rates
23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
Focus
Auto Focus Available Using Compatible Lenses
Display
Screen Size
7"
Screen Resolution
1920 x 1200
Screen Type
LCD Capacitive Touchscreen
Screen Brightness
600 nits
Controls
Touchscreen Menus, Rotary Settings Dial, Program Button, F1/F2/F3 Assignable Buttons, Brightness/Contrast/Peaking Dials
Mounting
2 x 1/4" Tripod Mount
Connectivity
SDI Video Inputs
1
SDI Video Outputs
1
SDI Rates
1.5G, 3G, 6G, 12G
HDMI Video Outputs
1 x HDMI 2.0
Analog Audio Input
1 x 3.5mm Stereo Input (also accepts Timecode)
Analog Audio Output
1 x 3.5mm TRRS Mini Jack for Headphones with Mic
SDI Audio Output
2 Channels Program Audio Embedded; Talkback on Channels 15 and 16
Remote Control
Remote Camera Control over SDI, HDMI, or USB Ethernet
Computer Interface
2 x USB Type-C 3.1 Gen 1 (up to 5Gb/s)
Audio
Microphone
Integrated Stereo Microphone
Built-In Speaker
1 x Mono Speaker
Audio Sampling (SDI)
48 kHz, 24-bit
Audio Sampling (HDMI)
48 kHz, 24-bit
Standards
HD Video Standards
1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
SDI Compliance
SMPTE 292M, SMPTE 424M, SMPTE 425M Level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10
Media and Storage
Media Interface
2 x USB-C 3.1 Gen 1 Expansion Ports for External Recording
Supported File Systems
ExFAT (Windows/Mac), HFS+ (Mac)
Recording Formats
Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3, Q5 in Ultra HD 3840 x 2160
Storage Rates
Based on 30 fps
Color and Control
Color Corrector
DaVinci YRGB
External Control
Blackmagic Control Protocol over SDI and HDMI; Camera Control REST API over USB Ethernet
External Lens/Camera Control
Blackmagic Zoom Demand and Blackmagic Focus Demand via USB-C
Network Management
NTP
Yes
Web Media Manager
Yes
FTP
Yes
SMB File Sharing
Yes
Power
Power Supply
1 x External 12V DC 60W
Power Input
1 x 12V DC Locking 5.5mm Barrel Connector
Power Usage
15–22W
Environmental
Operating Temperature
0° to 40° C (32° to 104° F)
Storage Temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% Non-Condensing
Included Items
Included
Blackmagic Studio Camera 4K Plus G2, Sun Shade, Tripod Mount Compatible with 15mm Lightweight Rails, Turret Dust Cap, External 12V DC Power Supply with Locking Connector and International Socket Adapters
Certifications
Warranty
1 Year Limited Manufacturer's Warranty
