Blackmagic Design HyperDeck Studio 4K Pro

Blackmagic Design HyperDeck Studio 4K Pro

SoundPro Item: 121838 | Part Number: BMD-HYPERD/ST/DG4P

$1,865.00
$1,865.00 $1,865.00
Your Price Sold out
MSRP: $1,865.00 | MAP: $1,865.00

Usually ships in 5-7 business days

  • Professional broadcast decks that record and playback using SD cards and SSD media
  • Ideal for live production, broadcast, and archive
  • Bright color LCD status display
  • Traditional broadcast deck controls
  • Supports SD cards, UHS-II cards or SSDs
  • Dual media slots for non-stop recording
  • Record to external USB-C media disks
  • Supports popular ProRes, DNx, H.264 and H.265 files
  • Advanced broadcast connections include 3G-SDI, 6G-SDI, 12G-SDI and HDMI
  • Fill and key outputs for broadcast animations
  • USB webcam output for video software
  • Advanced HDR support and monitoring 3D LUTs
  • Includes professional multi channel SDI audio
  • Incredibly fast network file transfers
  • Traditional RS-422 broadcast deck control
  • Built-in timecode and sync generators
  • Powered by Blackmagic OST
  • Use all video software and streaming sites
  • Built-in redundancy keeps you on air
  • Compatible with switchers, disk docks, and cameras
Log in or register for YOUR best price

Take your recording above and beyond with the HyperDeck Studio 4K Pro from Blackmagic Design. This extremely powerful and advanced member of the HyperDeck Studio family records and plays H.264/5, ProRes, and DNx files in all SD, HD, and Ultra HD standards up to 2160p60, and it also records SD and HD in H.264 and Ultra HD in H.265. It’s the perfect piece of gear for a wide variety of projects, ranging from broadcast, live production, multi-screen digital signage, and much more!

Blackmagic Design’s HyperDeck Studio Series

Every member of the HyperDeck Studio series from Blackmagic Design is intended to provide versatile tools and powerful performance, no matter what your recording needs. Record broadcast-quality video files directly to SD cards and SSD media. HyperDeck Studio models boast a sleek, modern design, intuitive controls, more codecs, and quieter cooling—the perfect addition (or foundation) of any studio. All models support recording to H.264, Apple ProRes, or DNxHD files with either PCM or AAC audio. Mount recorded media to any computer, giving you access to files from your favorite video software. When it comes to ISO recording, you can use the onboard timecode and reference generators to easily sync multiple units.

More about the HyperDeck Studio 4K Pro

In addition to all the premium features of its counterparts, the HyperDeck Studio 4K Pro features incredible processing for working in Ultra HD. It uses H.264 for SD and HD recording, then switches to H.265 for recording Ultra HD. The HyperDeck Studio 4K Pro comes with 2 redundant AC power supplies. Its networking has been upgraded to 10G Ethernet, providing excellent speed.

The HyperDeck Studio 4K Pro features enhanced 12G-SDI with a loop 12G-SDI output. Its 2 SDI outputs are also 12G-SDI, allowing you to play ProRes 4444 files for true Ultra HD fill and key out. Its HDMI connections, ProRes file formats, and DNx file formats all switch between SD, HD, and Ultra HD television standards, giving you control over your recording quality.

View full details

Specifications

Certifications
Standards
HD Video Standards 720p50, 720p59.94, 720p601080i50, 1080i59.94, 1080i601080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p601080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, Color Space REC 601, REC 709, REC 202033 point 3D LUTS can be applied to SDI monitor out
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10, SMPTE 2084 and SMPTE 2108-1
Dimensions
Dimensions (H X W X D)
1.74 x 19 x 9.3 inches
Electrical
Power Requirements
Power Supply 2 x Internal 100 - 240V AC 50/60Hz1 x 4 pin XLR 12V DC In for external power supply or battery use
Audio
Audio Output
1 x 6.35 mm headphone jack
Black Burst.SDI Audio Inputs
16 channels embedded audioSDI
Audio Outputs
16 channels embedded audioHDMI
Audio Inputs
8 channels embedded audioHDMI
Audio Sampling
Television standard 24-bit, 48 kHz sample rate
Connectivity
SDI Video Inputs
1
SDI Video Outputs
2
SDI Monitor Outputs
1
HDMI 2.0 Video Inputs
1
HDMI 2.0 Video Outputs
1
Supported HDMI Formats
525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60, 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI
Construction
Color Precision
10-bit
Controls
Blackmagic HyperDeck Ethernet Protocol.Ethernet
10Gb/sComputer
Built in Control Panel
16 buttons for transport and device control with search dial featuring electronic clutch and 2.2 inch color display.
Displays
Built in 2.2 inch LCD for video, audio and timecode monitoring and menu settings, LED bezel indicator lights around SSD media slots and LED indicator lights above the SD media slots
Environmental
Operating Temperature
0° to 40° C (32°to 104° F)
Storage Temperature
-20° to 60° C (-4° to 140° F)
Relative Humidity
0% to 90% non-condensing
Shipping
Weight
5.57 lbs
General
SDI Rates
270Mb, 1.5G, 3G, 6G, 12G
Built in Speaker
Mono
Screen
2.2 inch LCD
Timecode Connections
1 x XLR In, 1 x XLR Out
Control
1 x RS-422 In, 1 x
RS-422 OutRecorder Configuration
Via user interface or
Interface
1 x USB Type-C 3.1 Gen 2 (up to 10Gb/s) for external drive recording, webcam out, software configuration and updates
SD Video Standards
525i59.94 NTSC, 625i50 PAL
2K DCI Video Standards
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
4K DCI Video Standards
4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI
SDI Metadata Support
HD RP188 and closed captioning CEA-708. HDR Metadata supported on SDI
Video Sampling
4:2:2 YUV
HDR Support
Hybrid Log-Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084
Multi Rate Support
Auto detection of SD, HD, 6G-SDI and 12G-SDI
Copy Protection
HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
Media
Media 2 x 2.5 inch disc slots2 x SD card slots1 x USB-C 3.1 Gen 2 expansion port for external recording of SD, HD, 2K DCI, Ultra HD and 4K DCI, Media Type SATA-II or SATA-III 2.5 inch solid state mediaUHS-I and UHS-II SD cards
Media Format
Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems
Supported Codecs
ProRes HQ QuickTime, ProRes 422 QuickTime, ProRes LT QuickTime, ProRes Proxy QuickTime for all formats up to 2160p60. Playback only of ProRes 4444 QuickTime up to 2160p60 with auto routing of fill and key over SDI A and B outputs. DNxHD 220x, DNxHD 220x MXF, DNxHD 145, DNxHD 145 MXF, DNxHD 45, DNxHD 45 MXF for 720p and 1080p HD formats up to 60fps.DNxHR HQX, DNxHR HQX MXF, DNxHR SQ, DNxHR SQ MXF, DNxHR LB, DNxHR LB MXF for 2K DCI and 2160p formats up to 60fps. H.265 SDI 4:2:2 10-bit, H.265 High 4:2:0 10-bit, H.265 Medium 4:2:0 10-bit, H.265 Low 4:2:0 10-bit for all 2160p formats up to 60 fps. H.264 SDI 4:2:2 10-bit, H.264 High 4:2:0 8-bit, H.264 Medium 4:2:0 8-bit, H.264 Low 4:2:0 8-bit for all formats up to 1080p60.
External Control
RS-422 deck control, SDI start/stop, timecode run. Includes Blackmagic HyperDeck Ethernet Protocol. Supports remote FTP file upload.
Software
Software Included Blackmagic OSBlackmagic HyperDeck Setup
Internal Software Upgrade
Loaded at system start, or via Blackmagic HyperDeck Setup using USB port
Operating Systems
Mac 10.15 Catalina, Mac 11.1 Big Sur or later, Windows 10, 64-bit
Power Usage
100 W max.
Physical Installation
1 rack unit height
