Specifications
Dimensions
Effective Sensor Size
17.78mm x 10mm (Four Thirds)
Screen Dimensions
7 inch 1920 x 1200
Dimensions
10.77" x 6.59" x 6.68"
Audio
Signal to Noise Ratio
63dB for 2160p
Analog Audio Input
1 x 3.5mm Stereo Input. Can also be used for Timecode input
Analog Audio Output
1 x 3.5mm mini jack for headphones
Microphone
integrated stereo microphone
HDMI Audio Sampling
Television standard sample rate of 48 kHz and 24-bit
Optics
Focus
auto focus available using compatible lenses
Connectivity
HDMI 2.0 Video Outputs
1
Power Inputs
1 x 12V DC locking 5.5 mm barrel connector
Construction
Lens Mount
active MFT mount
Lens Control
iris, focus, zoom on supported lenses
Color Corrector
DaVinci YRGB
Environmental
Operating Temperature
32°F to 104°F (0°C to 40°C)
Relative Humidity
0% to 90% non-condensing
General
Dynamic Range
13 stops
Dual Native ISO
0 dB and 18 dB gain
Camera Features
Sensitivity at 0 dB gain, Frame Rates, Mounting Options
Shooting Resolutions
3840 x 2160 (Ultra HD) up to 60 fps
Screen Type
LCD capacitive touchscreen
Screen Brightness
600 nits
Controls
Touchscreen camera settings and menus with rotary settings dial, program button, F1, F2 and F3 assignable function buttons, brightness contrast and peaking dials
Remote Control
remote camera control over HDMI
Computer Interface
2 x USB Type-C 3.1 Gen 1 (up to 5Gb/s) expansion ports for external recording and focus / zoom demand connection. Software updates using USB-C Port A
Built-in Speaker
1 x mono speaker
SD Video Standards
none
HD Video Standards
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
Media
2 x USB-C 3.1 Gen 1 expansion ports for external media for recording Blackmagic RAW
Media Format
Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems
Supported Codecs
Blackmagic RAW Constant Bitrate 3:1, Blackmagic RAW Constant Bitrate 5:1, Blackmagic RAW Constant Bitrate 8:1, Blackmagic RAW Constant Bitrate 12:1, Blackmagic RAW Constant Quality Q0, Blackmagic RAW Constant Quality Q1, Blackmagic RAW Constant Quality Q3, Blackmagic RAW Constant Quality Q5
Storage Type
2 x USB-C 3.1 Gen 1 expansion ports for external media
Recording Formats
Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3 and Q5 in Ultra HD 3840 x 2160 at the selected frame rate
Storage Features
Storage Rates (based on 30 frames per second)
External Control
Blackmagic Zoom Demand and Blackmagic Focus Demand for controlling your camera and lens from tripod handles
Live Tally Indicator
1x front facing for talent, 1x rear facing for operator
Software
Blackmagic Camera Setup for Mac and Windows
Operating Systems
Mac 10.15 Catalina, Mac 11.1 Big Sur or later, Windows 10, 64-bit
Power Supply
1 x External 12V DC 60W power supply
Power Usage
15 - 22 W
