Specifications
Dimensions
Screen Dimensions
4 inch
Optics
Focus
Focus button turns on peaking (auto focus available using compatible lenses)
Iris Control
Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses so no pixel is clipped in film mode. Scene average auto exposure in video mode.
Construction
Lens Mount
EF mount included (interchangeable with optional PL, B4 and F lens mounts)
Lens Control
Electronic control via EF mount pins or 12pin broadcast connector for compatible lenses
General
Effective Sensor
Size 25.34mm x 14.25mm (Super35)
Dynamic Range
15 Stops
Shooting Resolutions
4608 x 2592, 4608 x 1920 (4.6K 2.40:1), 4096 x 2304 (4K 16:9), 4096 x 2160 (4K DCI), 3840 x 2160 (Ultra HD), 3072 x 2560 (3K Anamorphic), 2048 x 1152 (2K 16:9), 2048 x 1080 (2K DCI), 1920 x 1080
Frame Rates
Maximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported.
High Speed Frame Rates
Blackmagic RAW 8:1, 4.6K Full - Up to 120 fps, UHD Windowed - Up to 150 fps, HD Windowed - Up to 300 fps, ProRes 422 HQ, 4.6K Full - Up to 80 fps, UHD Windowed - Up to 120 fps, HD Windowed - Up to 240 fps
Built in ND Filters
Four position ND filter wheel with clear, 2-stop, 4-stop and 6-stop ND filters
Screen Type
LCD capacitive touchscreen
Metadata Support
Automatically populated lens data from electronic EF, B4 and i/Technology compatible PL lenses. Automatic recording of camera settings and slate data such as project, scene number, take and special notes.
Controls
Touchscreen menus on 4 inch screen, push buttons for other controls, 2 assignable shortcut keys
Timecode Clock
Highly accurate timecode clock, less than 1 frame drift every 8 hours
