Sonance Blaze Audio CBL528 Bi-Amped Loudspeaker For Installed Audio | Black
Sonance Blaze Audio CBL528 Bi-Amped Loudspeaker For Installed Audio | Black
SoundPro Item: 143432 | Part Number: CBL528-BA-B
Usually ships in 5-7 business days
- Bi-Amped Constant-Beamwidth Loudspeaker For Permanent Commercial Installations
- 54Hz-18kHz Frequency Range With Symmetrical 180° H x 45° V Dispersion
- LF: 320W AES (1280W Peak) @ 5.2Ω | HF: 200W AES (800W Peak) @ 8Ω
- Consistent Coverage Whether Listeners Are In Front, Off-Axis, Or Moving
- Ideal For Fitness, Sports Venues, Conference Centers, And Houses Of Worship
- Black Cabinet Finish
The Sonance Blaze Audio CBL528 is a compact bi-amped constant-beamwidth loudspeaker designed for permanent installations where consistent coverage and intelligibility matter across the entire listening area. The cabinet supports a frequency range of 54 Hz to 18 kHz, with a symmetrical 180-degree horizontal by 45-degree vertical dispersion that keeps music natural and speech articulate whether listeners are directly in front, off to one side, or moving through the space.
Bi-amped operation separates low-frequency (320W AES @ 5.2Ω) and high-frequency (200W AES @ 8Ω) sections for the cleanest possible transient response and the highest available headroom from a cabinet this size. The black finish suits typical commercial interiors, while the controlled directivity makes the CBL528 well suited to fitness and sports venues, conference centers, multipurpose rooms, and houses of worship where listener positions move and shift during a session.
Bi-amped operation requires an amplifier with at least two output channels per cabinet — one for LF, one for HF — or a single Lo-Z amplifier configured to drive each section separately. Pair the CBL528 with PowerZone or PowerZone Connect amplifiers in the same project for matched system tuning and warranty alignment.
Downloads
Downloads

- Frequency Response (-3 dB)*54 Hz - 18 kHz
- Frequency Range (-10 dB) 48 Hz - 18 kHz
- Horizontal Nominal Dispersion (-6dB) 180°
- Vertical Nominal Dispersion (-6 dB) 45°
- Max SPL @ 1 W / 1 m 121 dB SPL (131 dB SPL peak)
- Dimensions (HxWxD) 19.46x19.45x15.99” (494.3x494x406.16mm)
- Weight 38.5 lbs (17.46 kg)
