Blaze Audio CCA10i 2x10-Inch Passive Arrayable Point Source Speaker | Color: White

Blaze Audio CCA10i 2x10-Inch Passive Arrayable Point Source Speaker | Color: White

SoundPro Item: 143431 | Part Number: CCA10i-BA-W

$6,000.00
$6,000.00 $6,000.00
Your Price Sold out
MSRP: $6,000.00 | MAP: $6,000.00

Usually ships in 5-7 business days

  • Available in black or white (white not pictured)
  • 3-way Arrayable Point Source, designed for Bi-Amping
  • Constant Curvature waveguide for unprecedented array coherence
  • Precision 160 Degree Symmetrical Horizontal pattern control
  • Variable vertical coverage in 20° increments (one enclosure 20° and max 12 enclosures)
  • Dual 10” ultra low distortion, high excursion drivers
  • System range 52 Hz – 18 kHz
  • Exceptionally high SPL
  • Rugged Polyurea coating for extreme durability
  • System integration with BLAZE amplifiers
Log in or register for YOUR best price

The CCA10 is a compact arrayable point source loudspeaker, designed for medium-sized venues to large distributed systems that need a flexible, scalable speaker solution.

Mounted horizontally with tight acoustic centers to minimize comb filtering, each CCA10 enclosure provides a fixed 20° vertical coverage and can be flown with additional enclosures in vertical arrays.

Featuring a coaxial compression driver that uses separate midrange and high-frequency polymer ring- shaped diaphragms, the compression driver delivers an extremely wide response from 420 Hz – 18,000 Hz. Two 10” high-excursion ultra-low distortion drivers offer reduced power compression, providing efficient and accurate bass reproduction downto 52 Hz.

View full details
  • Frequency Response (-3dB)*52 Hz - 18 kHz
  • Frequency Range (-10 dB) 45 Hz - 18 kHz
  • Horizontal Nominal Dispersion (-6dB) 160°
  • Vertical Nominal Dispersion (-6 dB) 20°
  • Max SPL @ 1W/1m (2.83v) 131 dB SPL (140 dB SPL peak)
  • Dimensions (HxWxD) 13.23x32.33x18.25" (336.14x821.21x463.68mm)
  • Weight 83lbs (37.65kg)
