Blaze Audio CCA10i Bi-Amped Loudspeaker Arrayable | White
Blaze Audio CCA10i Bi-Amped Loudspeaker Arrayable | White
SoundPro Item: 143431 | Part Number: CCA10i-BA-W
Usually ships in 5-7 business days
- Compact Arrayable Point-Source Loudspeaker For Medium-Sized Venues
- Dual 10-Inch High-Excursion LF Drivers - Accurate Bass Down To 52Hz
- Coaxial Compression Driver With 420Hz-18kHz Mid/HF Response
- Fixed 20° Vertical Coverage - Flyable In Vertical Arrays For Larger Throws
- LF: 500W AES (2000W Peak) @4Ω | HF: 110W AES (440W Peak) @8Ω
- Tight Acoustic Centers Minimize Comb Filtering Between Cabinets
- White Cabinet Finish For Production AV And Architectural Installs
The Blaze Audio CCA10i is a compact, arrayable point-source loudspeaker built for medium-sized venues and scalable distributed systems. Two 10-inch high-excursion ultra-low distortion drivers deliver accurate, efficient bass reproduction down to 52 Hz, while a coaxial compression driver with separate midrange and high-frequency polymer ring-shaped diaphragms extends response from 420 Hz to 18 kHz with the tight acoustic centers needed to minimize comb filtering between cabinets.
Each CCA10i mounts horizontally and provides a fixed 20-degree vertical coverage that can be combined with additional cabinets in vertical arrays for larger throw distances and SPL requirements. Power handling is rated at 500W AES low-frequency (2000W peak @ 4Ω) and 110W AES high-frequency (440W peak @ 8Ω). The white cabinet finish suits the production-grade aesthetics of corporate AV, broadcast, houses of worship, theatrical rentals, and architectural concert installations.
For installations that need additional sub-bass weight, pair with the BL18S passive subwoofer. For arrayed deployments, specify the matching CCA10i Rigging Grid rather than third-party rigging hardware — the engineered grid maintains the CCA10i's tight acoustic centers and preserves Sonance's published load and safety ratings.
