Specifications
Electrical
Power Consumption
663W, 5.8A
Optics
Beam Angle
60°
Controls
Protocol
USITT DMX-512
General
Overview
32-bit dimming curves, Variable electronic dimming & strobe, Automated temperature control, Static color mixing, Flicker-free, constant-current driver, Mounting bracket w/stabilizers, powerCON® compatible AC power In/Out
Light Source
256 x (64* R/G/B/W) 3W LEDs
Luminous Intensity
2,076 Lux @ 2m | 376 Lux @ 5m
Control
9/15/27-channel DMX modes, Standalone, master/slave mode, 3/5-pin XLR In/Out connections, 4-button control panel w/Micro OLED display
PF
.99
Power
Power
100-264VAC, 47-63 Hz
