Specifications
Dimensions
Gobo Size
22.9mm outer, 18mm inner, 2mm max thickness
Dimensions (LxWxH)
15x9.8x21.7"
Electrical
Power Consumption
283W, 2.49A
Controls
Protocol
USITT DMX-512
Shipping
Weight
35.1 lbs
General
Luminous Intensity
38,405 Lux @ 2.5M (narrow), 13,058 Lux @ 2.5M (wide), 9,937 Lux @ 5M (narrow), 3,241 Lux @ 5M (wide), 4,668 Lux @ 7.5M (narrow), 1,543 Lux @ 7.5M (wide), 2,746 Lux @ 10M (narrow), 916 Lux @ 10M (wide)
Optical
200W white LED light engine, 60,000 hours, Fast and precise zoomable beam angle (13°- 27°), Flicker-free LED
Control
3/5-pin DMX in/out, Easy-to-use 5-button control panel with LCD display
Operating Modes
DMX512, master/slave, auto mode
PF
.99
Control
DMX Channels
16/19-channel modes
Power
Power
90-250VAC, 50-60 Hz, PowerCON™ TRUE1-compatible AC power In/Out connectors
