Blustream IP200UHD-TX HDMI over IP 4K Video Transmitter
Blustream IP200UHD-TX HDMI over IP 4K Video Transmitter
SoundPro Item: 123995 | Part Number: IP200UHD-TX
Usually ships in 5-7 business days
- Advanced UHD video over 1Gb Network
- Virtually unlimited system size
- Extends HDMI up to a distance of 100m over a single CAT cable
- Supports up to 4K HDR UHD video sources (3840 x 2160 @ 30Hz 4:4:4, 4096 x 2160 @ 24Hz 4:4:4, and 4K @ 60Hz 4:2:0)
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio transmission
- 4 different operational modes
- Advanced signal management for independent routing of IR, RS-232, USB/KVM, audio and video
- PoE (Power over Ethernet) to power Blustream products from PoE switch
- HDCP2.2 compliant with advanced EDID management
- Analog L/R audio embedding
- Analog L/R audio breakout
- Local 24-56V power supply (should Ethernet switch not support PoE) - sold separately
Blustream's UHD Multicast distribution platform allows virtually latency free (1 frame) distribution of HDMI video over a 1Gb Network switch.
The IP200UHD-TX is an industry leading 4K HDCP 2.2 HDMI transmitter that uses visually lossless compression technology to deliver HDMI, Bi-directional IR, RS-232 & USB / KVM up to lengths of 100m over standard network architecture.
The IP200UHD-TX can be powered via PoE from the Network switch or locally should the switch not support PoE. With multiple configuration options available, the Multicast solution is ideal for both commercial and residential installations.
Operational Modes
- Matrix distribution (requires 1Gb network switch)
- Video wall (requires 1Gb network switch)
- One-to-one HDMI extender (no network switch required)
- One-to-many HDMI extender (no network switch required)
- Video Input1 x HDMI Type A, female
- Video Output1 x LAN RJ45 connector
- Audio Input1 x 3.5mm L/R Analog audio
- Audio Output Connectors2 x RCA L/R Analog audio
- Ethernet Port1 x LAN RJ45 connector
- RS-232 Serial Port1 x 3-Pin Phoenix connector
- USB / KVM Port1 x USB - Type B
- IR Input1 x 3.5mm stereo jack
- IR Output1 x 3.5mm mono jack
- Firmware Update1 x Micro-USB
- Operating Temperature32°F to 104°F (0°C to 40°C)
- Storage Temperature-4°F to 140°F (-20°C to 60°C)
- Dimensions (WxDxH)7.48" x 4.49" x 0.98"
