- Enclosure MaterialEngineered plastics
- EnvironmentalIndoor only
- GrillePerforated steel, powder-coated finish
- LogoRotatable, removable
- Suspension/Mounting1 suspension attachment point, 1 safety cable attachment point
- Operating Temperature Range0 °C to 50 °C (32 °F to 122 °F)
- Product Dimensions (HxWxD)8.2 in x 9.8 in (207 mm x 248 mm), loudspeaker diameter x depth / 15.0 ft x 0.1 in (4.6 m x 2 mm), suspension cable length x diameter
- Net Weight5.5 lb (2.5 kg), single
- Shipping Weight15.4 lb (7.0 kg), pair
- Frequency Range (-10 dB)75 Hz - 20,000 Hz
- Coverage, Horizontal130° conical
- Calculated Maximum SPL @ 1 m99 dB
- Nominal Impedance8 Ω (transformer bypass)
- Power Handling, long-term continuous25 W
- Power Handling, Peak100 W
- Recommended Signal ProcessingNot required, Bose Professional EQ voicing and SmartBass processing available
- Sensitivity (SPL/1 W at 1 m)84 dB
- Transformer Taps, 100V6, 12, 25 W, bypass
- Transformer Taps, 70V3 W, 6 W, 12 W, 25 W, bypass
- Coverage, Vertical130° conical
- Crossover1.7 kHz, passive 2-way crossover
- Driver ProtectionRecommended high-pass protection 80 Hz with minimum 24 dB/octave filter
- High-Frequency1 x 0.75 in (20 mm) neodymium dome tweeter, coaxially mounted
- Low-Frequency1 x 3.25 in (83 mm) woofer
