Bose AudioPack Pro S4 Background Music and Paging System | White

Bose AudioPack Pro S4 Background Music and Paging System | White

SoundPro Item: 147729 | Part Number: 892256-1210

$999.00
$999.00 $999.00
Your Price Sold out
MSRP: $999.00 | MAP: $999.00

Usually ships in 5-7 business days

  • EN 54-24 Certification Ensures Compliance For Life Safety Paging Applications
  • Opti-Voice EQ And Dynamic Low-End Compensation Maintain Clarity Across Varying Program Levels
  • Integrated DSP With FreeSpace Loudspeaker Presets Eliminates External Processing Hardware
  • Dual-Channel Architecture With Page Priority Supports Independent Source Zones
  • Plenum-Rated Loudspeaker Construction Meets Commercial Building Code Requirements
  • Removable Rotatable Logos And Powder-Coated Grilles Blend Into Customer-Facing Environments
Log in or register for YOUR best price

AudioPack Pro delivers turnkey background music and paging infrastructure for commercial environments where consistent sound quality and ease of installation determine project success. The system pairs a FreeSpace IZA 190-HZ integrated zone amplifier with FreeSpace FS in-ceiling transducers, pre-matched for tonal consistency and reliable voice intelligibility across retail, hospitality, and corporate installations.

Class D amplification provides 90 watts at 70V or 100V, with dual channels supporting independent source routing and page priority. Built-in DSP presets align amplifier response to FreeSpace loudspeaker models, while Opti-Voice EQ optimizes paging clarity without external processing. Front-panel controls manage input selection, tone shaping, and master level; rear DIP switches configure amplifier mode and loudspeaker equalization for specific transducer models.

FreeSpace FS loudspeakers feature 2.25-inch woofers in engineered-plastic baffles with integrated steel backcans, designed for plenum-rated ceiling installations. Rotatable, removable logos and perforated steel grilles maintain visual discretion in customer-facing spaces. The system scales to business requirements with available package configurations and supports expansion when additional coverage zones are required.

View full details

Specifications

Certifications
EN 54-24 Certified
Yes
Audio
Rated Power
90 W at 70V, 100V
Number of Channels
2
Power Class
Class D
Frequency Response
60 Hz – 20 kHz (+0 dB/-3 dB) at 1 W, 1 kHz reference
Dynamic Range
88 dB
Channel Separation
≤ -60 dBV below rated power, 1 kHz
THD+N
≤ 1% at full rated power
Frequency Range (-10 dB)
83 – 19,000 Hz
Calculated Maximum SPL @ 1 m
98 dB
Sensitivity (SPL/1 W at 1 m)
86 dB
Coverage Horizontal
150°
Coverage Vertical
150°
Connectivity
Input Channels
2 unbalanced line + 1 balanced mic/line + 1 balanced mic (page) + 1 unbalanced line (auxiliary)
Input Connectors
(1) RCA stereo pair, (1) XLR-1/4-in combo, (1) 4-pin Euroblock, (1) 1/8-in (3.5 mm) TRS
Output Channels
1
Output Connectors
(1) 3-pin inverted Euroblock, (1) RCA stereo pair
Input Impedance
20 kΩ line / 2 kΩ mic/line / 2 kΩ page / 20 kΩ auxiliary
Output Impedance
N/A (amplifier) / 400 Ω (auxiliary)
Input Range
-10 dBV to +10 dBV line / -60 dBV to +10 dBV mic/line / -60 dBV to +10 dBV page / 0 dBV to +10 dBV auxiliary
Maximum Input Level
+10 dBV
Nominal Input Level
0 dBV line / -40 dBV mic/line / -40 dBV page / 0 dBV auxiliary
Sensitivity
0 dBV auxiliary / N/A line, mic/line, page
Adjustment Range
-20 dB to +20 dB line / 0 dB to +50 dB mic/line / 0 dB to +50 dB page / fixed auxiliary
Electrical
Mains Voltage
100–240 VAC (±10%), 50/60 Hz
Mains Connector
IEC C14 inlet
AC Power Consumption
15 W idle, 200 W maximum
Current Draw Inrush
7.6 A at 120 VAC, 60 Hz / 13.9 A at 230 VAC, 50 Hz
Protections
High temperature, short circuit
Nominal Impedance
16 Ω (transformer bypass)
Power Handling Long-Term Continuous
16 W
Power Handling Peak
64 W
Transformer Taps 70V
1 W, 2 W, 4 W, 8 W, 16 W, bypass
Transformer Taps 100V
2, 4, 8, 16 W, bypass
DSP
A/D and D/A Converters
48 kHz / 24-bit
Audio Latency
10.4 ms (analog input to analog output)
Presets
High-pass filter, Bose Professional loudspeaker presets (FreeSpace FS2C/FS2P/FS2SE/FS4CE/FS4SE)
Processing Functions
Loudspeaker EQ, Opti-Voice EQ (paging), Dynamic EQ (low-end compensation)
Controls
Front Panel
(1) power switch, (1) input selection switch, (1) treble knob, (1) bass knob, (1) mic/line gain knob, (1) master level knob
Rear Panel
Amplifier Mode DIP switch, Loudspeaker EQ preset selector, Input Gain (A/B/Page mic), Output trim
LED Status Indicators
(1) power LED, (1) input clip LED
Construction
Colors
White (similar to RAL 9003)
Enclosure Material
Engineered-plastics front baffle with integrated steel-formed backcan
Grille
Perforated steel, powder-coated finish
Logo
Rotatable, removable
Suspension/Mounting
(2) mounting arms, (1) safety cable attachment point
Cooling System
Natural convection
Rack Spaces
1 RU high, half rack wide
Environmental
Operating Temperature Range
0 °C to 50 °C (32 °F to 122 °F)
Environmental
Indoor only, suitable for use in plenum locations (loudspeakers only)
Physical
Ceiling Cutout
6.3 in (160 mm)
Net Weight Loudspeaker
3.6 lb (1.6 kg) with grille (single)
Net Weight Amplifier
7.0 lb (3.2 kg)
Transducers
Low-Frequency
1 × 2.25 in (57 mm) woofer
Driver Protection
Recommended high-pass protection 85 Hz with minimum 24-dB/octave filter
