Specifications
Weight
Net Weight
9.1 lb (4.1 kg), single
Shipping Weight
24.3 lb (11.0 kg), pair
Audio
Crossover
1.8 kHz, passive 2-way crossover
Construction
Enclosure Material
Engineered plastics
Grille
Perforated steel, powder-coated finish
Environmental
Operating Temperature Range
0 °C to 50 °C (32 °F to 122 °F)
General
Environmental
Indoor only
Logo
Rotatable, removable
Suspension/Mounting
1 suspension attachment point, 1 safety cable attachment point
Product Dimensions (HxWxD)
10.2 in x 11.8 in (259 mm x 300 mm), loudspeaker diameter x depth / 15.0 ft x 0.1 in (4.6 m x 2 mm), suspension cable length x diameter
Frequency Range (-10 dB)
65 Hz - 20,000 Hz
Coverage, Horizontal
120° conical
Calculated Maximum SPL @ 1 M
105 dB
Nominal Impedance
8 Ω (transformer bypass)
Power Handling, Long-term Continuous
50 W
Power Handling, Peak
200 W
Recommended Signal Processing
Not required, Bose Professional EQ voicing and SmartBass processing available
Sensitivity (SPL/1 W at 1 m)
87 dB
Transformer Taps, 100V
6, 12, 25, 50 W, bypass
Transformer Taps, 70V
3 W, 6 W, 12 W, 25 W, 50 W, bypass
Coverage, Vertical
120° conical
Driver Protection
Recommended high-pass protection 65 Hz with minimum 24 dB/octave filter
High-Frequency
1 x 1 in (25 mm) neodymium dome tweeter, coaxially mounted
Low-Frequency
1 x 5.25 in (133 mm) woofer
