Specifications
Dimensions
Filter Diameter
58mm
Dimensions
Approx. 168x173x333 mm (approx. 6.6x6.8x13.1 in.) [body only (excluding grip belt)], Approx. 200x219x385 mm (approx. 7.9x8.6x15.2 in.) [Including lens hood, eyecup and mic holder unit]
Electrical
Power Supply (rated)
14.4V DC (battery pack), 24V DC (DC In)
Audio
Microphone
Stereo (using electret condenser microphone)
Audio Terminal
3.5mm stereo mini-jack, XLR 3-pin jack (two channels)
Connectivity
Input/Output
USB Terminal Type-C, SuperSpeed USB (USB 3.2 gen 1x1) supported, PTP class supported, UVC Supported Type-A, USBHOST supported (max. voltage: 5V / max. output current: 900 mA)
HDMI Terminal
HDMI™ connector (Type A)
Construction
Lens
Canon 15x Zoom, 8.3-124.5mm (35mm equivalent 25.5-382.5mm), f/2.8-4.5
Shipping
Weight
Approx. 4.4 lbs. / 2010g (including grip belt; excluding hood, mic holder unit, eyecup, battery)
General
Standard Definition Or High Definition
4K Ultra High Definition
Image Sensor
1.0-inch 4K UHD CMOS Sensor
Total Pixels
Approx. 13.4 megapixels (4268x3148)
Effective Pixels
Approx. 8.29 megapixels (3840x2160)
Video Recording System XF-AVCCompression
MPEG-4 AVC/H.264Color Sampling: 4:2:2 10-bitFile Format: MXFRecording Modes Resolution: 3840x2160 (YCC422 10-bit) 260 Mbps Long GOP (59.94P/50.00P)410 Mbps Intra-frame (29.97P/25.00P/23.98P)160 Mbps Long GOP (29.97P/25.00P/23.98P)Resolution: 1920x1080 (YCC422 10-bit) 310 Mbps Intra-frame (59.94P/50.00P)160 Mbps Intra-frame (29.97P/25.00P/23.98P/59.94i/50.00i)50 Mbps Long GOP (59.94P/50.00P/29.97P/25.00P/23.98P/59.94i/50.00i)Resolution: 1280x720 (YCC422 10-bit)MP4Compression: MP4 (HEVC): H.265/HEVCMP4 (H.264): MPEG-4 AVC/H.264Color Sampling: MP4 (HEVC): YCC422 10-bit/YCC420 10-bitMP4 (H.264): YCC420 8-bitFile Format: MP4Recording Modes: Resolution: 3840x2160 (YCC422 10-bit) 225 Mbps (59.94P/50.00P) / 135 Mbps (29.97P/25.00P/23.98P)Resolution: 1920x1080 (YCC422 10-bit) 50 Mbps (59.94P/50.00P/29.97P/25.00P/23.98P)Resolution: 1280x720 (YCC422 10-bit) 12 Mbps (59.94P/50.00P)Resolution: 3840x2160 (YCC420 10-bit) 170 Mbps (59.94P/50.00P) / 100 Mbps (29.97P/25.00P/23.98P)Resolution: 1920x1080 (YCC420 10-bit) 35 Mbps (59.94P/50.00P/29.97P/25.00P/23.98P)Resolution: 1280x720 (YCC420 10-bit) 9 Mbps (59.94P/50.00P)(2) MP4 (H.264): (YCC420 8-bit)Resolution: 3840x2160 150 Mbps (59.94P/50.00P/29.97P/25.00P/23.98P)Resolution: 1920x1080 35 Mbps (59.94P/50.00P/29.97P/25.00P/23.98P)Resolution: 1280x720 8 Mbps (59.94P/50.00P)
Maximum Recording Time vXF-AVC
32
GB card410 Mbps
9 min.310
Mbps
12 min.260
MP4 (HEVC)
32 GB card 225
MP4 (H.264)
32 GB card 150
Mpbs
501 min.64 GB card 150
Frame Rate
60p, 30p, 24p
Recording Media
SD card [x2] (SD/SDHC/SDXC)
Recording System Linear PCM
24-bit / 48 kHz / 4-channel (XF-AVC)Linear
PCM
16-bit / 48 kHz / 4-channel (MP4)MPEG-2 AAC LC 16-bit / 48 kHz / 2-channel (MP4)
Focusing System
Dual Pixel CMOS AF w/Eye Detection
Minimum Focusing Distance
10mm at wide end, 60cm across entire zooming range
Image Stabilization
Optical system (lens shift) + electronic stabilization (Image rotation and camera movements in the yaw and pitch directions are electronically corrected.)
Modes
Dynamic IS, Powered IS, Standard IS, IS Off
Manual Exposure
Yes
Max Shutter Speed
1/2000
Minimum Illumination
Approx. 1.5 lux (with 1/30 sec. shutter speed, 29.997P)
Genlock Terminal
Yes
Timecode Terminals
Yes
Video Terminal
HDMI™ connector, 12G-SDI terminal
Headphone Terminal
3.5mm stereo mini-jack
12G-SDI Terminal
Yes
Ethernet Terminal
Ethernet connector (RJ-45) (supports 1000BASE-T)
Viewfinder
0.36-inch color OLED display, approx. 1.77 million dots, approx. 100% field of view
LCD Screen
3.5-inch LCD, (Approx. 2.76 million dots)
For Performance
Approx. 0-40° C, 85% (relative humidity)
For Operation
Approx. -5-45° C, 60% (relative humidity)
