Specifications
Certifications
Approvals
CE, MET
Dimensions
Gobo Size
M 66 mm outside, 48 mm image, 2 mm max thickness
Accessory holder/gel Frame Size
6.3" x 6.3" / 6.24" x 6.24"
Dimensions
24" x 7.2" x 16.9"
Electrical
Power and Current
106 W, 0.9 A @ 120 V, 60 Hz; 103 W, 0.5 A @ 230 V, 50 Hz
Optics
Manual Zoom Angle
14° to 30°
Color Temperature
3500K
Controls
DMX Connectors
3-pin XLR
Strobe Rate
0 to 30 Hz
Shipping
Weight
12.6 pounds (5.7 kg)
General
Light Source
1 LED (warm white) 100 W (2.3 A), 50,000 hours life expectancy
14° at 2m
15,100 lux
30° at 2m
3,800 lux
30° at 5m
829 lux
Power Linking
9 units @ 120 V; 16 units @ 230 V
CRI
80
Control
DMX Channels
1 or 3
Power
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
