Specifications
DMX
Channels
4, 6, or 14
Connectors
3-pin XLR
Max Unobstructed Distance
600 ft (183 m)
Light Source
LEDs
12 quad-color RGBA, 6 W each
Life Expectancy
50,000 hours
Beam Angle
12°
Field Angle
23°
Illuminance
4,185 lux @ 2 m
Illuminance With Diffuser
1,005 lux @ 2 m
Lumens
1,255
Performance
Strobe Rate
0 to 20 Hz
Maximum Run Time
up to 7 hours
Maximum Run Time Single Color
up to 9.5 hours
Recharge Time
4 hours
Wireless
Operating Frequency
2.412 to 2.484 GHz
Power
Input Voltage
24 VDC, 1.5 A
External Power Supply
24 VDC, 50/60 Hz
Power Draw
22 W, 0.3 A @ 120 V, 60 Hz
Power Draw
22 W, 0.2 A @ 230 V, 50 Hz
Physical
Weight
5.4 lbs (2.4 kg)
Dimensions
8.7 x 7.8 x 4.8 in (222 x 197 x 123 mm)
Environmental
Startup Temperature
-4°F to 113°F (-20°C to 45°C)
Operating Temperature
-22°F to 113°F (-30°C to 45°C)
Certifications
Approvals
CE, RoHS, FCC
Compatibility
Optional Controllers
RFC, RFC-XL
Included Items
External power supply
Yes
Magnetic diffuser
Yes
Quick Reference Guide
Yes
