Specifications
Certifications
Approvals
CE, RoHS
DMX
Channels
3, 6, or 11
Connectors
3-pin XLR
Optical
Beam Angle
20°
Field Angle
36°
Illuminance
5,657 lux @ 2 m
Lumens
3,239
Light Source
Wash LEDs
18 quad-color RGBW, 52 W, 50,000 hours
Ring LEDs
51 RGB, 6 W, 50,000 hours
Strobe Rate
0 to 20 Hz
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current
63 W, 0.9 A @ 120 V, 60 Hz
Power and Current
62 W, 0.6 A @ 230 V, 50 Hz
Power Linking
8 units @ 120 V; 12 units @ 230 V
Construction
Bracket Mounting Hole
13 mm
Dimensions
Product Size
10.8" x 2.7" x 12"
Package Size
19.69" x 14.17" x 12.99"
Weight
Product Weight
3.0 lbs
Package Weight
20.72 lbs
Compatibility
Optional Controllers
IRC-6
Recommended Bag
CHS-40 VIP Gear Bag
Included Items
Included Accessories
Power cable, Quick Reference Guide
